CORROSION MONITOR ASSEMBLY

The UNITED Fire Systems CMA-1 is a device for monitoring the possible corrosion inside of a wet or dry sprinkler system piping. The assembly consists of a corrosion probe in a chamber, a pressure switch, an isolation valve, and a drain valve. The corrosion probe keeps pressure from reaching the pressure switch. When corrosion perforates the probe, pressure reaches the pressure switch, actuating a signal and providing early warning of possible corrosion inside the piping. The isolation valve allows replacement of the corrosion probe without depressurizing the entire system, and the drain valve safely vents pressure from the probe chamber.

Technical Data

  • Inlet Connection = 1/2” NPT female
  • Pressure Switch Setting Range = 4 to 8 PSIG
  • Switch Contact Ratings = 10 A @ 125 / 250 VAC and 2 A @ 30 VDC
  • Maximum Recommended Inlet Pressure = 300 PSIG

Contact UNITED Fire Systems Today

Give us a call at 908.688.0300 or contact us online to request more information about our Sprinkler Accessories.

Resources

Data Sheets +-

Instruction Sheets +-

Warranty Information +-

Did You Know?

  • Your wet-pipe sprinkler system may not be as filled with water as you expect it to be. A bubble of air may migrate to the highest point in the system, creating a very vulnerable location for internal pipe corrosion. That’s why NFPA 13 now requires that all new wet sprinkler systems be fitted with an air vent at the system’s highest point. This is a good investment for both new and existing systems. The UNITED Fire Systems Model AR-1 automatic air vent device is Factory Mutual (FM) Approved for just this function. See here for more information, and take action to prevent damaging corrosion.
